*PLC control
*Over-wrap count to create a cover
*Reinforce wrap count to keep goods stable
*Film Tension Control adjustment on the panel
*Separate start, pause and emergency stop buttons
*Manual carriage up/down control
*Variable Turntable Speed control
*Carriage up/down speed control
|
Turntable diameter |
1650mm |
|
Turntable speed |
0-12rpm |
|
Turntable Height |
85mm |
|
Turntable weight capacity |
2000kg |
|
Power supply |
220V 50/60HZ 1Phase (standard) |
|
Air consume lever |
0.6-1.0Mpa |
|
Wrapping Height |
1000-1800mm |
|
Packing efficiency |
20-40 loads / hour |
|
Material |
LLDPE - Stretch Film |
|
Film Thickness |
17-35 µm |
|
Film Width |
500 mm |
|
Core Diameter |
76.2 mm |
|
Machine weight |
650 / 700kg |
|
Machine dimention |
2450mm*1500mm*2750mm |
|
Package Dimention |
2845mm*1650mm*1150mm |
|
Maximum Film. Diameter |
260 mm |
|
Max. weight of film roll |
15 kg |
